20KG Battery Lithium Ferrous Phosphate 2688Wh High Current 12.8 Volt Lifepo4 Battery
Product Details
| Voltage | 12.8V | Capacity | 210Ah |
|---|---|---|---|
| Weight | 20KG | Storage Range | -5°C~35°C |
| Low Temperature Charging Heating | Optional | Cycle Life | >3000 Times, 0.5C, 80% DOD 25°C |
| Protection Level | IP65 | Certification | UN38.3, IEC 62619 |
Product Description
Camel Energy UT-2688A 210Ah Capacity LFP Battery with IP65 Protection and 3000+ Cycles for RVs and Solar Systems
Quick Detail
- Brand: Camel Energy
- Model: UT-2688A
- Nominal Voltage: 12.8V
- Nominal Capacity: 210Ah
- Energy: 2688Wh
- Cycle Life: >3000 cycles (0.5C, 80% DOD)
- IP Rating: IP65
- Certification: UN38.3
- Terminal: M8 Threaded Studs
- Dimensions (W*D*H): 363*212*230mm
- Weight: 20kg
- Bluetooth: Optional
- Low‑temp Heating: Optional
- Warranty: 36 Months
Product Description
Camel Energy UT-2688A is a high‑capacity 12V lithium iron phosphate battery designed for large‑power mobile, off‑grid, and backup applications. Built with a rugged ABS shell, intelligent BMS, optional Bluetooth monitoring, and low‑temperature heating, it delivers stable, maintenance‑free 24/7 operation. With IP65 protection, high current support, and long cycle life, it is an ideal drop‑in replacement for traditional lead‑acid batteries in RVs, marine, solar systems, and heavy‑duty equipment.
Product Specification
| Parameter | Value |
|---|---|
| Nominal Voltage | 12.8V |
| Nominal Capacity | 210Ah |
| Rated Energy | 2688Wh |
| Dimensions (W*D*H) | 363*212*230mm |
| Weight | 20kg |
| Charge Cut-off Voltage | 14.6V |
| Discharge Cut-off Voltage | 10.8V |
| Max. Charge Current | 150A |
| Max. Discharge Current | 150A |
| Recommended Charge Temp | 0°C~55°C |
| Recommended Discharge Temp | -20°C~60°C |
| Storage Temperature | -5°C~35°C |
| BMS Protection | Over/under voltage, over/low temp, short circuit, auto cell balancing |
| Low-temp Heating (Optional) | ≤0°C auto start; >5°C auto stop |
| Bluetooth Monitoring | Optional (Voltage/Current/Temp/SOC) |
| IP Rating | IP65 |
| Certification | UN38.3 |
| Cycle Life | >3000 cycles (0.5C, 80% DOD) |
| Package | Battery*1, User Manual*1, M8*12mm*2 |
Product Application
- Large RVs, camper vans, motorhomes
- Marine yachts, fishing boats, sailing vessels
- Off‑grid solar energy storage systems
- High‑power backup power supplies
- Outdoor engineering & emergency power
- Golf carts, utility vehicles, sweepers
- Industrial equipment & test instruments
Product Features
- Ultra‑high Capacity – 210Ah for long‑lasting power supply
- High Current Output – 150A max charge/discharge
- Smart BMS – Full protection + automatic cell balancing
- IP65 Waterproof & Dustproof – Suitable for harsh environments
- Optional Low‑temp Heating – Supports charging at -20~0°C
- Optional Bluetooth – Real‑time mobile APP monitoring
- Multiple Operating Modes – Charge / discharge / standby / sleep
- UN38.3 Certified – Safe for global transportation
Product Advantage
- Lighter & smaller than equivalent lead‑acid batteries
- Maintenance‑free, no liquid replenishment required
- Stable voltage output, no sudden drop
- Wide temperature range: -20°C~60°C discharge
- Safe LFP chemistry, no thermal runaway risk
- Low self‑discharge, long standby time
- 36‑month official warranty
- Standard M8 terminals for easy installation
FAQ
Q1: How to monitor battery status?
A: Use the optional Bms Blue Tooth APP to view real‑time SOC, voltage, current, and temperature.
Q2: How does low‑temperature heating work?
A: Heating activates automatically at ≤0°C (with external power) and stops at >5°C to ensure normal charging.
Q3: How to wake the battery from sleep mode?
A: Apply charging voltage ≥12.8V or discharge current >800mA.
Q4: What to do if the battery shuts down?
A: Reactivate by connecting a charger with voltage ≥12.8V.
Q5: Does it support simultaneous charge and discharge?
A: No, this operation is strictly prohibited.
Q6: What are the storage requirements?
A: Store at 15–35°C, recharge every 3 months, avoid direct sunlight and heat sources.
Q7: What does the 36‑month warranty cover?
A: Covers defects under proper operation and installation; excludes improper use, disassembly, or physical damage.
