12.8V Lion Lithium Iron Phosphate Battery 38.5KG UN38.3 420ah Lifepo4
Product Details
| Voltage | 12.8V | Capacity | 420Ah |
|---|---|---|---|
| Weight | 38.5KG | Storage Range | -5°C~35°C |
| Low Temperature Charging Heating | Optional | Cycle Life | >3000 Times, 0.5C, 80% DOD |
| Protection Level | IP65 | Certification | UN38.3, IEC 62619 |
Product Description
Camel Energy UT-5376A 420Ah Capacity LFP Battery with IP65 Protection and 3000+ Cycles
Quick Detail
- Brand: Camel Energy
- Model: UT-5376A
- Nominal Voltage: 12.8V
- Nominal Capacity: 420Ah
- Energy: 5376Wh
- Cycle Life: >3000 cycles (0.5C, 80% DOD)
- IP Rating: IP65
- Certification: UN38.3
- Terminal: M8 Threaded Studs
- Weight: 38kg
- Bluetooth: Optional
- Low‑temp Heating: Optional
- Warranty: 36 Months
Product Description
Camel Energy UT-5376A is an ultra‑high‑capacity 12V lithium iron phosphate battery designed for large‑scale off‑grid, marine, RV, and backup power applications. Built with a rugged ABS shell, intelligent BMS, optional Bluetooth monitoring, and low‑temperature heating, it delivers stable, maintenance‑free 24/7 operation. With IP65 protection, high current support, and long cycle life, it is the ideal high‑capacity replacement for traditional lead‑acid batteries.
Product Specification
| Parameter | Value |
|---|---|
| Nominal Voltage | 12.8V |
| Nominal Capacity | 420Ah |
| Rated Energy | 5376Wh |
| Weight | 38kg |
| Dimensions (W*D*H) | 640*245*220mm |
| Charge Cut-off Voltage | 14.6V |
| Discharge Cut-off Voltage | 10.8V |
| Max. Charge Current | 150A |
| Max. Discharge Current | 150A |
| Recommended Charge Temp | 0°C~55°C |
| Recommended Discharge Temp | -20°C~60°C |
| Storage Temperature | -5°C~35°C |
| BMS Protection | Over/under voltage, over/low temp, short circuit, auto cell balancing |
| Low-temp Heating (Optional) | ≤0°C auto start; >5°C auto stop |
| Bluetooth Monitoring | Optional (Voltage/Current/Temp/SOC) |
| IP Rating | IP65 |
| Certification | UN38.3 |
| Cycle Life | >3000 cycles (0.5C, 80% DOD) |
| Package | Battery*1, User Manual*1, M8*12mm*2 |
Product Application
- Large RVs, motorhomes, yachts
- Off‑grid solar & wind energy storage
- Large backup power systems
- Outdoor engineering & emergency power
- Industrial equipment & base stations
- Marine deep‑cycle power supply
Product Features
- Ultra‑high Capacity – 420Ah for long‑duration power supply
- High Current Output – 150A max charge/discharge
- Smart BMS – Full protection + automatic cell balancing
- IP65 Waterproof & Dustproof
- Optional Low‑temp Heating
- Optional Bluetooth Monitoring
- Multiple Operating Modes
- UN38.3 Certified
Product Advantage
- High capacity, long runtime
- Lighter than lead‑acid of same capacity
- Maintenance‑free
- Stable voltage output
- Wide temperature adaptability
- Safe LFP chemistry
- Low self‑discharge
- 36‑month warranty
FAQ
Q1: How to monitor battery status?
A: Use the optional Bms Blue Tooth APP to view real‑time SOC, voltage, current, temperature.
Q2: How to wake from sleep mode?
A: Apply charging voltage ≥12.8V or discharge current >800mA.
Q3: What to do if battery shuts down?
A: Reactivate with charger ≥12.8V.
Q4: Does it support simultaneous charge/discharge?
A: No.
Q5: Storage requirements?
A: 15–35°C, recharge every 3 months.
