Camel LV5200
Category:
LV Wall-Mounted Residential Energy Storage System Camel LV5200 LV Wall-Mounted Residential Energy Storage System Camel LV5200 offers capacity options from 5 to 20 kWh and features high safety and intelligent monitoring capabilities. It is perfectly compatible with mainstream inverters, and the installation is straightforward, easily manageable by one to two people.
Tel：
Introduce
Camel LV5200--Racked Residential Energy Storage Low-voltage Battery Pack
Flexible Investment
Lead acid replacement； Suitable for rack or cabinet using
Easy Installation
Compact and Light Easy installation by 1-2 person
Excellent low temp. performance
Operate at -10°C without any limitation and attenuation
Perfectly Compatible
Compatible with mainstream brand inverters
Product Parameter:
|
Model |
LV5200-5 |
LV5200-10 |
LV5200-15 |
LV5200-20 |
LV5200-25 |
LV5200-30 |
LV5200-35 |
LV5200-40 |
|
Number of Parallel |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
|
Rated Power(kWh) |
5.12 |
10.24 |
15.36 |
20.48 |
25.6 |
30.72 |
35.84 |
40.96 |
|
Rated Voltage(V) |
51.2 |
|||||||
|
Charge/Discharge cut off Voltage(V) |
46.4~55.2 |
|||||||
|
Rated Charge/Discharge Current(A) |
50/50 |
100/100 |
150/150 |
200/200 |
200/200 |
200/200 |
200/200 |
200/200 |
|
Max. Charge/Discharge Current(A) |
50/100 |
100/200 |
150/200 |
200/200 |
200/200 |
200/200 |
200/200 |
200/200 |
|
Communication Interface |
CAN 2.0/RS485 |
|||||||
|
Protection Features |
Charging overvoltage protection, discharge under –voltage protection, over current protection, over temperature protection ,short circuit protection, etc. |
|||||||
|
IP Rating |
IP20/IP65 |
|||||||
|
Altitude |
<2000m |
|||||||
|
Weight(kg) |
45 |
90 |
135 |
180 |
225 |
270 |
315 |
360 |
|
Opertating Temperature Range |
Charge:-10~50°C；Discharge:-20~50°C |
|||||||
|
Storage Temperature Range |
-20°C~50°C |
|||||||
|
Humidity Range |
10%~95%,non condensation |
|||||||
|
Size(W*H*D,mm) |
482*135*433/PACK |
|||||||
|
Safety |
UL 1973/UL 9540/IEC 62619 |
|||||||
|
Transport |
UN38.3 |
|||||||
